Sipa XP20LQ 4K Laser 3LCD Home Cinema Projector
Product Overview
The Sipa XP20LQ is a 4K laser 3LCD home cinema projector designed for premium living rooms, dedicated home theaters, private screening rooms, and large-screen residential applications. With ≥4200 lumens ISO brightness, SONY BrightEra 7th-generation 0.64-inch 3LCD panels, SONY image processing, 4K Enhancement, HDR10 support, wide color space capability, flexible lens options, and low-noise operation, it delivers a bright, stable, and cinema-like viewing experience for modern home entertainment.
Key Features
• Nichia long-life laser light source
• ≥4200 lumens ISO brightness
• SONY BrightEra 7th-generation 0.64-inch 3LCD laser LCD panels
• SONY image processing platform for 4K Enhancement, HDR10, Gamma adjustment, and color optimization
• 4K Enhancement resolution with up to 4K 3840×2160 / 60Hz signal input
• HDR10 / 10-bit / 1.07 billion colors
• Native contrast ≥1,000:1 and dynamic contrast ≥6,000,000:1
• Wide color space support: BT.709, DCI-P3, and BT.2020
• Two standard lens options: 1.08–1.76:1 / 1.2–2.0:1
• Four optional original lenses: 0.38:1, 0.52–0.64:1, 0.68–0.82:1, and 1.68–2.8:1
• Lens vertical shift +60% and image vertical shift +10%
• Keystone correction, 4-corner correction, and curved screen adjustment
• Low-noise operation, ≤26dB
• SANYO DENKI San Ace quiet cooling system with intelligent thermal control
• Dual HDMI 2.0 input with CEC, EDID compatibility, and HDMI 1 ARC audio return
• RS232 and RJ45 network control for smart home and AV control integration
Technical Specifications
| Technical Specifications | |
|---|---|
| Model | XP20LQ |
| Color Options | Gunmetal Gray / White |
| Display Technology | SONY BrightEra 7th-generation 0.64-inch 3LCD laser LCD panels |
| Image Processing | SONY image processing and LCD driving platform with Sipa home cinema picture tuning |
| Light Source | Nichia laser light source |
| Light Source Life | 25,000 hours in standard mode; up to 30,000 hours in eco mode |
| Resolution | 4K Enhancement |
| Input Signal | Up to 4K 3840×2160 / 60Hz |
| ISO Brightness | ≥4200 lumens |
| Native Contrast Ratio | ≥1,000:1 |
| Dynamic Contrast Ratio | ≥6,000,000:1 |
| HDR / Color Depth | HDR10 / 10-bit / 1.07 billion colors |
| Color Space Support | BT.709, DCI-P3, and BT.2020; typical coverage ≥100% BT.709 |
| Image Uniformity | ≥90% |
| Standard Lens Options | 1.08–1.76:1 / 1.2–2.0:1 |
| Optional Original Lenses | 0.38:1, 0.52–0.64:1, 0.68–0.82:1, 1.68–2.8:1 |
| Lens Vertical Shift | +60% |
| Image Vertical Shift | +10% |
| Geometry Correction | Keystone correction, 4-corner correction, and curved screen adjustment |
| Noise Level | ≤26dB |
| Cooling System | SANYO DENKI San Ace quiet cooling system with PWM intelligent speed control and speed feedback |
| Eye Comfort / Light Safety | Designed to meet EN 50689:2021 home projector light source safety requirements |
| HDMI | Dual HDMI 2.0 input, CEC, EDID compatibility optimization, HDMI 1 ARC audio return |
| Control | RS232 control, RJ45 network control, PJ-Link protocol support |
| Audio | 16W speaker, S/PDIF digital audio output |
| Remote Control | Smart home dual-IR remote control; supports image freeze, local zoom, and one-key blank screen |
| Housing | High-strength engineering plastic housing with anti-static surface treatment |
| Warranty & Service | For authorized home-channel units with SN registration and valid home warranty certificate: 3-year warranty and 280-day replacement service for verified quality issues. Regional terms may vary. |
Feature Highlights
Installation Flexibility
The XP20LQ offers two standard lens choices and four optional original lenses, making it suitable for different home cinema room layouts and whole-home projection scenarios. Lens vertical shift helps with optical alignment, while image vertical shift allows fine adjustment of the 16:9 image within the 16:10 LCD panel area, reducing dependence on digital correction and helping preserve image clarity.
Application Scenarios
The Sipa XP20LQ is designed for premium living rooms, dedicated home theaters, private screening rooms, and large-screen residential applications. It is suitable for users who require high brightness, stable 3LCD color performance, flexible installation, quiet operation, and a reliable 4K laser projection system.
Warranty & Service
For Sipa home projectors sold through authorized home channels, completed with SN registration and a valid home warranty certificate, the XP20LQ is covered by a 3-year warranty and a 280-day replacement service for verified quality issues. Warranty policy may vary by region. Please contact Sipa or local distributors for details.
Note: Brightness, noise, lifetime, color gamut, contrast ratio, and other specifications may vary depending on test environment, operating mode, lens configuration, installation method, and product batch. Final information is subject to official filed documents, product nameplate, packaging label, and formal test reports. Specifications are subject to change without prior notice.
