Sipa XP20SQ 4K Laser 3LCD Short Throw Home Cinema Projector
Product Overview
The Sipa XP20SQ is a 4K laser 3LCD short throw home projector designed for living rooms, bedrooms, private screening rooms, and compact home cinema spaces. With ≥5100 lumens ISO brightness, 4K Enhancement, HDR10 support, a 0.44:1 short throw lens, and low-noise operation, it delivers a bright, comfortable, and flexible large-screen viewing experience for home entertainment.
Key Features
4K laser 3LCD short throw home cinema projector
≥5100 lumens ISO brightness
SONY BrightEra 7th-generation 0.64-inch 3LCD panels
4K Enhancement resolution with up to 3840×2160 / 60Hz input
0.44:1 short throw ratio, suitable for large images in compact spaces
Approximately 100-inch 16:9 image from around 1 meter projection distance
Vertical image shift: ±5%
HDR10, 10-bit color depth, 1.07 billion colors
Supports BT.709, DCI-P3 and BT.2020 color spaces
Low-noise operation, ≤26dB
Gunmetal gray and white cabinet options
Technical Specifications
| Item | Specification |
|---|---|
| Model | XP20SQ |
| Color Options | Gunmetal gray and white |
| Light Source | Nichia laser light source |
| Light Source Life | 25,000 hours in standard mode; up to 30,000 hours in eco mode |
| ISO Brightness | ≥5100 lumens |
| Display Technology | SONY BrightEra 7th-generation 0.64-inch 3LCD panels |
| Image Processing | SONY image processing chip with Sipa home cinema image tuning |
| Resolution | 4K Enhancement |
| Input Signal | Up to 3840×2160 / 60Hz |
| Native Contrast Ratio | ≥1,000:1 |
| Dynamic Contrast Ratio | ≥6,000,000:1 |
| HDR / Color Depth | HDR10 / 10-bit / 1.07 billion colors |
| Color Gamut | Supports BT.709, DCI-P3 and BT.2020 color spaces; typical coverage: ≥100% BT.709, ≥95% DCI-P3; supports BT.2020 color space |
| Image Uniformity | ≥90% |
| Throw Ratio | 0.44:1 |
| Projection Distance Reference | Approximately 100-inch 16:9 image from around 1 meter projection distance |
| Image Shift | Vertical ±5% |
| Geometry Adjustment | Keystone correction, 4-corner correction and arc-screen correction |
| Noise Level | ≤26dB |
| Cooling System | SANYO DENKI San Ace home-use low-noise cooling system |
| Eye Comfort | Meets EN 50689:2021 home projector light source safety requirements |
| Remote Control | Front and rear dual IR receivers; smart home remote operation |
| HDMI Input | Dual HDMI 2.0 inputs; supports CEC, EDID compatibility optimization and HDMI 1 ARC audio return |
| Smart Home Control | RS232 control interface and RJ45 network control; supports PJ-Link and integration with AV control systems |
| Speaker | 16W speaker |
| Audio Output | S/PDIF digital audio output |
| Cabinet Protection | High-strength material with anti-static coating |
| Product Dimensions | 390 × 319 × 157 mm, including lens protrusion |
| Net Weight | Approx. 6.2 kg |
| Max Power Consumption | 350W max |
| Standby Power | ≤0.5W |
Feature Highlights
Short Throw Installation
With a 0.44:1 short throw lens, the XP20SQ can create a large 16:9 image in a short projection distance. It is suitable for compact rooms, living rooms and bedrooms where space is limited. Short throw installation helps reduce shadow interference when people move near the screen and provides a cleaner setup for home entertainment.
Application Scenarios
The Sipa XP20SQ is designed for home cinema, living room entertainment, bedroom projection, private screening rooms and compact residential spaces. It is suitable for users who require a bright 4K laser 3LCD large-screen display in a limited projection distance.
Warranty & Service
For Sipa home projectors sold through authorized home-channel distributors with registered SN records and valid home-use warranty certificates, the XP20SQ is covered by a 3-year whole-unit warranty and a 280-day replacement service for verified quality issues.
Warranty policy may vary by region. Please contact Sipa or local distributors for details.
Note: Brightness, noise level, light source life, color gamut, contrast ratio and other specifications may vary depending on testing environment, operating mode, lens configuration, installation method and product batch. Final specifications are subject to company-registered documents, product nameplate, packaging labels and official test reports. Product specifications are subject to change without prior notice.
